Chauvin Arnoux F603 Clamp Meter, Max Current 3kA ac, 3000A dc CAT III 1000 V, CAT IV 1000 V With RS Calibration

Technical Reference
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): CN
Product Details

F603 AC/DC TRMS Clampmeter

The F603 clampmeter is designed for the high-power LV market in sectors such as elctrical power distribution, chemical and petrochemical industries, metallurgy, transport
The main applications are maintenance, testing, monitoring, diagnostics, sizing connection
Equipped with a fast 12-bit TRMS digital acquisition system
The large backlit triple display makes it easy to read in all circumstances
Automatic AC/DC detection
Resistance and audible continuity
TrueInrush current measurement
Min and Max analysis
Relative and differential measurements
Temperature
Adapter function
IP54 protection

Specifications
Attribute Value
Absolute Maximum AC Current Measurement 3kA ac
Absolute Maximum DC Current Measurement 3000A dc
Absolute Maximum AC Voltage Measurement 1400V ac
Absolute Maximum DC Voltage Measurement 1400V dc
Absolute Maximum Resistance Measurement 99.99W
Model Number F603
Calibrated RSCAL
Best DC Current Accuracy ±1% + 3 Digits
Clamp Meter Type Continuity Tester, Voltage & Current Tester
Best AC Current Accuracy ±1% +3 digits
Best AC Voltage Accuracy ±1% + 3 Digits
Best DC Voltage Accuracy ±1% + 3 Digits
Power Source Battery
Dimensions 92 x 41 x 272mm
Length 92mm
Width 41mm
True RMS Yes
Functions Measured AC Current, AC Voltage, DC Current, DC Voltage, Resistance, Temperature
Maximum Conductor Size 48mm
Height 272mm
Minimum Operating Temperature -60°C
Maximum Operating Temperature +1000°C
Display Type LCD
Safety Category CAT III 1000 V, CAT IV 1000 V
Absolute Maximum Temperature Measurement +1000°C
Battery Type AA
Safety Category Voltage 1000V
Weight 600g
Safety Category Level CAT III, CAT IV
Available to back order for despatch 20.08.2020
Price Each
kr 5 597,70
(exc. VAT)
kr 6 997,12
(inc. VAT)
Units
Per unit
1 +
kr 5 597,70
Not available for next day delivery
