RS PRO Circular Connector, 5 Contacts, Panel Mount, M12 Connector, Socket, Female, IP67
- RS Stock No.:
- 124-6712
- Brand:
- RS PRO
Available to back order for despatch 25.06.2024
Added
Price Each
Kr. 145,31
(exc. VAT)
Kr. 181,64
(inc. VAT)
| Units | Per unit |
| 1 - 9 | Kr. 145,31 |
| 10 - 49 | Kr. 138,16 |
| 50 - 99 | Kr. 130,68 |
| 100 + | Kr. 123,31 |
- RS Stock No.:
- 124-6712
- Brand:
- RS PRO
Legislation and Compliance
RoHS Status: Not Applicable
- COO (Country of Origin):
- CN
Product Details
M12 Push-Pull Square Flange
From RS Pro, these push-pull sockets & plugs are serious contenders for your application. The convenient push-pull connection, makes it perfect in situations where accidental disconnects occur. That coupled with the IP67 rating, makes sure that this industrial connector excels in harsh environments. When choosing a male & female connector, this version should really be one you consider.
Features & Benefits
• Panel hole cutout diameter: 12 mm
• 2 way, 3 way, 4 way and 5 way all available
• Cable outer diameter: 4 mm to 6.5 mm. And 5 mm to 8 mm
• Solder termination
• Chrome plated brass shell material
• Square flange mount
• Gender: Male & Female
• 2 way, 3 way, 4 way and 5 way all available
• Cable outer diameter: 4 mm to 6.5 mm. And 5 mm to 8 mm
• Solder termination
• Chrome plated brass shell material
• Square flange mount
• Gender: Male & Female
RS Pro Push-Pull
Specifications
Attribute | Value |
|---|---|
| Number of Contacts | 5 |
| Mounting Type | Panel Mount |
| Connector Size | M12 |
| Plug/Socket | Socket |
| Contact Gender | Female |
| Termination Method | Solder |
| IP Rating | IP67 |
| Current Rating | 5.0A |
| Body Orientation | Straight |
| Voltage Rating | 180 V |
| Mating Type | Push-Pull |
| Housing Material | Metal |
| Pole Format | 5P |
| Contact Plating | Gold |
| Contact Material | Brass |
| Maximum Operating Temperature | +85°C |
| Minimum Operating Temperature | -40°C |
