RS PRO Circular Connector, 3 Contacts, Panel Mount, M12 Connector, Plug, Male, IP67
- RS Stock No.:
- 124-6723
- Brand:
- RS PRO
6 In stock for same day dispatch
Added
Price Each
Kr. 180,07
(exc. VAT)
Kr. 225,09
(inc. VAT)
| Units | Per unit |
| 1 - 9 | Kr. 180,07 |
| 10 - 49 | Kr. 170,83 |
| 50 - 99 | Kr. 162,36 |
| 100 + | Kr. 153,12 |
- RS Stock No.:
- 124-6723
- Brand:
- RS PRO
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
M12 Push-Pull Front Mount
From RS Pro, these push-pull plugs & sockets are serious contenders for your application. The convenient push-pull connection, makes it perfect in situations where accidental disconnects occur. That coupled with the IP67 rating, makes sure that this industrial connector excels in harsh environments. When choosing a male or female connector, this version should really be one you consider.
Features & Benefits
• Panel hole cutout diameter: 12 mm
• 2 way, 3 way, 4 way and 5 way all available
• Cable outer diameter: 4 mm to 6.5 mm. And 5 mm to 8 mm
• Solder termination
• Chrome plated brass shell material
• Front Mounted
• Gender: Male & Female
• 2 way, 3 way, 4 way and 5 way all available
• Cable outer diameter: 4 mm to 6.5 mm. And 5 mm to 8 mm
• Solder termination
• Chrome plated brass shell material
• Front Mounted
• Gender: Male & Female
RS Pro Push-Pull
Specifications
Attribute | Value |
|---|---|
| Number of Contacts | 3 |
| Mounting Type | Panel Mount |
| Connector Size | M12 |
| Plug/Socket | Plug |
| Contact Gender | Male |
| Termination Method | Solder |
| IP Rating | IP67 |
| Current Rating | 13.0A |
| Body Orientation | Straight |
| Series | SF1212 |
| Voltage Rating | 250 V |
| Mating Type | Push-Pull |
| Housing Material | Metal |
| Pole Format | 3P |
| Contact Plating | Gold |
| Minimum Operating Temperature | -40°C |
| Contact Material | Brass |
| Maximum Operating Temperature | +85°C |
