Phoenix Contact SPTAF 1/14-3.5-EL Series PCB Terminal Block, 14-Contact, 3.5mm Pitch, Through Hole Mount, 2-Row, Screw
- RS Stock No.:
- 151-1457
- Mfr. Part No.:
- 1862246
- Brand:
- Phoenix Contact
58 In stock for same day dispatch
Added
Price Each
Kr. 64,57
(exc. VAT)
Kr. 80,71
(inc. VAT)
| Units | Per unit |
| 1 - 9 | Kr. 64,57 |
| 10 - 24 | Kr. 62,81 |
| 25 - 49 | Kr. 59,62 |
| 50 - 99 | Kr. 56,76 |
| 100 + | Kr. 54,12 |
- RS Stock No.:
- 151-1457
- Mfr. Part No.:
- 1862246
- Brand:
- Phoenix Contact
Technical Reference
Legislation and Compliance
Product Details
PCB terminal block, nominal current: 16 A, nom. voltage: 160 V, pitch: 3.5 mm, number of positions: 14, connection method: Push-in spring connection, mounting: Wave soldering, conductor/PCB connection direction: 45 °, Colour: green
Time saving push-in connection, tools not required
Defined contact force ensures that contact remains stable over the long term
Finger-operated release button for very convenient operation
Small component size for applications where space is at a premium
Quick and convenient testing using integrated test option
Defined contact force ensures that contact remains stable over the long term
Finger-operated release button for very convenient operation
Small component size for applications where space is at a premium
Quick and convenient testing using integrated test option
Specifications
Attribute | Value |
|---|---|
| Number of Contacts | 14 |
| Pitch | 3.5mm |
| Number of Rows | 2 |
| Mounting Type | Through Hole |
| Gender | Male |
| Termination Method | Screw |
| Type | PCB Terminal Block |
| Current Rating | 16A |
| Body Orientation | Angled |
| Colour | Green |
| Voltage Rating | 160 V |
| Series | SPTAF 1/14-3.5-EL |
| Width | 11mm |
| Length | 50.5mm |
| Depth | 12.8mm |
| Material | Polyamide |
