TRS, Temperature Sensors, 75C, +/-2.5C,

  • RS Stock No. 188-0939
  • Mfr. Part No. TRS5-75BLRU
  • Brand KEMET
Technical Reference
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): JP
Product Details

High reliability for on/off operationsHigh-speed response Long operational lifeExcellent environmental durabilityExtremely simple circuit designCompact, light and easy to handleDust, explosion and corrosion-proofWide range of operating temperatures available from −10°C to +130°CExcellent temperature accuracy of ±2.5°CApplicationsTypical applications include temperature detection and overheat monitoring of electric appliances, heat-retention heater control for rice cookers, defrost for air conditioners and vending machines, roll heater temperature control for copying machines, radiator water temperature detection for automotive electric fan control.

Attribute Value
Contact Configuration SPST-NC
Maximum Switching Current 0.5A
Maximum Switching Power 50W
Maximum Switching Voltage 140V ac
Contact Resistance 150mΩ
Contact Material Fe-Ni Alloy
Mounting Type Through Hole
Width 8.2 Dia. (Without Clamp)mm
Dimensions 8.2 Dia. x 50 (Without Clamp)mm
50 In stock for delivery within 1 working days
Price Each
kr 123,51
(exc. VAT)
kr 154,39
(inc. VAT)
Per unit
1 - 9
kr 123,51
10 - 24
kr 117,29
25 +
kr 114,96
