RS PRO PCB Slide Switch SPDT Latching 5 A @ 28 V dc Slide
- RS Stock No.:
- 734-7306
- Brand:
- RS PRO
17 In stock for same day dispatch
Added
Price Each
Kr. 19,03
(exc. VAT)
Kr. 23,79
(inc. VAT)
| Units | Per unit |
| 1 - 9 | Kr. 19,03 |
| 10 - 49 | Kr. 17,16 |
| 50 - 99 | Kr. 14,30 |
| 100 - 249 | Kr. 13,20 |
| 250 + | Kr. 12,10 |
- RS Stock No.:
- 734-7306
- Brand:
- RS PRO
Technical Reference
Legislation and Compliance
Product Details
RS - Miniature Slide Switches
Suitable for wave soldering at 260ºC for 5 seconds
Black nylon actuator, DAP case and stainless steel housing
Typical applications include PCB or front panel control for hand held products, instrumentation, white goods, medical, IT and telecomms equipment
Black nylon actuator, DAP case and stainless steel housing
Typical applications include PCB or front panel control for hand held products, instrumentation, white goods, medical, IT and telecomms equipment
Specifications
Attribute | Value |
|---|---|
| Contact Configuration | SPDT |
| Mounting Type | PCB |
| Switch Operation | Latching |
| Contact Current Rating | 5 A @ 28 V dc |
| Terminal Type | Through Hole |
| Actuator Type | Slide |
| Length | 12.7mm |
| Width | 6.6mm |
| Depth | 6.7mm |
| Dimensions | 12.7 x 6.6 x 6.7mm |
| Contact Resistance | 10mΩ |
| Voltage Rating | 28V dc |
| Mechanical Life | 30000Cycles |
| Actuator Material | Nylon |
| Contact Material | Silver Plated Brass |
| Minimum Operating Temperature | -30°C |
| Operating Temperature Range | -30 → +85°C |
| Maximum Operating Temperature | +85°C |
