FLIR E75 Thermal Imaging Camera, -20 → +120 °C, 320 x 240pixel Detector Resolution With RS Calibration
- RS Stock No.:
- 135-3316
- Mfr. Part No.:
- 78502-0101
- Brand:
- FLIR
Available to back order for despatch when stock is available
Not available for next day delivery
Added
Price Each
Kr. 76 833,91
(exc. VAT)
Kr. 96 042,39
(inc. VAT)
Units | Per unit |
1 + | Kr. 76 833,91 |
- RS Stock No.:
- 135-3316
- Mfr. Part No.:
- 78502-0101
- Brand:
- FLIR
Technical Reference
Legislation and Compliance
RoHS Status: Not Applicable
- COO (Country of Origin):
- EE
Product Details
FLIR EXX Series™ Advanced Thermal Imaging Cameras
FLIR EXX Series combines all the latest thermal imaging and communication features. The thermal camera offers superior sensitivity and a true 42° field of view in a user-friendly hand held platform. These cameras through infrared can detect even subtle indications of building deficiencies and moisture intrusion. They can offer on-screen area measurement so you can easily quantify and document air leaks, moisture and other building problems. A large touchscreen provides intuitive menu navigation and new technology allows lenses to be added or shared without factory recalibration.
Features and Benefits:
MSX® image enhancements add perspective to scenes, with edge detail on windows and doors
5 MP digital camera mode
Built-in voice annotation and customisable work folders make finding images easier
IR resolution 320 x 240 pixel
4" optically bonded PCAP touchscreen with 160° viewing angle
Rugged, water-tight chassis and scratch resistant Dragontrail™ cover glass
Fast, precise laser-assisted autofocus
Grip, trigger and buttons designed for easy one-handed operation
Sensitive enough to identify hidden building deficiencies
On-screen area measurement (E85, E95)
WiFi, METERLiNK® connectivity
True 42° field of view (FOV) lens allows for surveys of wide areas with a single lens, available separately 135-3296
5 MP digital camera mode
Built-in voice annotation and customisable work folders make finding images easier
IR resolution 320 x 240 pixel
4" optically bonded PCAP touchscreen with 160° viewing angle
Rugged, water-tight chassis and scratch resistant Dragontrail™ cover glass
Fast, precise laser-assisted autofocus
Grip, trigger and buttons designed for easy one-handed operation
Sensitive enough to identify hidden building deficiencies
On-screen area measurement (E85, E95)
WiFi, METERLiNK® connectivity
True 42° field of view (FOV) lens allows for surveys of wide areas with a single lens, available separately 135-3296
Supplied with
Infrared camera with 24° lens, battery (2), battery charger with power supply, front lens and light protection, hand and wrist straps, lanyards, lens caps (front and rear), lens cleaning cloth, 15 W3 A power supply, printed documentation, 8 GB SD card, torx screwdriver, cables (USB 2.0 A to USB Type-C, USB Type-C to HDMI, USB Type-C to USB Type-C), hard transport case.
Note
The Power supply, 15 W/3 A includes:
• EU plug
• UK plug
• US plug
• AU plug
• Korea plug
The Power supply for battery charger includes:
• EU plug
• UK plug
• US plug
• AU plug
• EU plug
• UK plug
• US plug
• AU plug
• Korea plug
The Power supply for battery charger includes:
• EU plug
• UK plug
• US plug
• AU plug
Specifications
Attribute | Value |
---|---|
Temperature Measurement Range | -20 → +120 °C |
Detector Resolution | 320 x 240pixel |
Display Resolution | 161 x 472pixel |
Model Number | E75 |
Thermal Sensitivity | 0.03 @ 30 °C |
Best Temperature Measurement Accuracy | ±2 % |
Focus Type | Automatic |
Calibrated | RSCAL |
Display Size | 4in |
Model Number p | E75 |
Application | Electrical, Mechanical |
Weight | 1kg |
