Toshiba 2SA1943N(S1,E,S) Transistor, -15 A PNP, -230 V, 3-Pin TO-3P
- RS Stock No.:
- 890-2620
- Mfr. Part No.:
- 2SA1943N(S1,E,S)
- Brand:
- Toshiba
Bulk discount available
Subtotal (1 pack of 5 units)*
Kr. 130,07
(exc. VAT)
Kr. 162,59
(inc. VAT)
FREE delivery for online orders over 750,00 kr
In Stock
- Plus 370 unit(s) shipping from 04 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 5 - 20 | Kr. 26,014 | Kr. 130,07 |
| 25 - 45 | Kr. 19,676 | Kr. 98,38 |
| 50 - 95 | Kr. 18,418 | Kr. 92,09 |
| 100 - 245 | Kr. 18,098 | Kr. 90,49 |
| 250 + | Kr. 17,732 | Kr. 88,66 |
*price indicative
- RS Stock No.:
- 890-2620
- Mfr. Part No.:
- 2SA1943N(S1,E,S)
- Brand:
- Toshiba
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Toshiba | |
| Product Type | Transistor | |
| Maximum DC Collector Current Idc | -15A | |
| Maximum Collector Emitter Voltage Vceo | -230V | |
| Package Type | TO-3P | |
| Mount Type | Through Hole | |
| Transistor Configuration | Single | |
| Maximum Collector Base Voltage VCBO | -230V | |
| Maximum Transition Frequency ft | 30MHz | |
| Minimum DC Current Gain hFE | 35 | |
| Maximum Emitter Base Voltage VEBO | -5V | |
| Minimum Operating Temperature | -55°C | |
| Transistor Polarity | PNP | |
| Maximum Power Dissipation Pd | 150W | |
| Maximum Operating Temperature | 150°C | |
| Pin Count | 3 | |
| Series | 2SA1943 | |
| Height | 40.5mm | |
| Standards/Approvals | No | |
| Length | 15.5mm | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand Toshiba | ||
Product Type Transistor | ||
Maximum DC Collector Current Idc -15A | ||
Maximum Collector Emitter Voltage Vceo -230V | ||
Package Type TO-3P | ||
Mount Type Through Hole | ||
Transistor Configuration Single | ||
Maximum Collector Base Voltage VCBO -230V | ||
Maximum Transition Frequency ft 30MHz | ||
Minimum DC Current Gain hFE 35 | ||
Maximum Emitter Base Voltage VEBO -5V | ||
Minimum Operating Temperature -55°C | ||
Transistor Polarity PNP | ||
Maximum Power Dissipation Pd 150W | ||
Maximum Operating Temperature 150°C | ||
Pin Count 3 | ||
Series 2SA1943 | ||
Height 40.5mm | ||
Standards/Approvals No | ||
Length 15.5mm | ||
Automotive Standard No | ||
PNP Power Transistors, Toshiba
Bipolar Transistors, Toshiba
