Norgren B07 Filter Regulator, 40μm, G 1/4, Automatic, 7 bar

Achieve precise control over the compressed air in your pneumatic system with this filter regulator from IMI Norgren. It maintains a stable air pressure at a pre-set level between 0.3 and 7 bar to optimise efficiency. With its 40μm filtration size, the filter regulator protects the performance of air-powered equipment by preventing solid and liquid contaminants from reaching the internal workings. The device's transparent polycarbonate (PC) bowl provides 360° visibility around the filter, letting you see clearly when it needs to be emptied.

• Zinc alloy housing is corrosion-resistant to minimise the risk of component wear even in humid conditions
• Features a spitter-type filter drain that automatically removes condensate after a quick change in airflow, keeping the filter clear for consistent performance
• Bowl attaches with a simple screw-on motion for quick assembly and maintenance

• Aerospace industry
• Medical and pharmaceutical manufacturing
• Compressed air cleaning equipment

The regulator mounts with a compatible wall bracket (123-923) and is secured with 3mm screws.
