Fluke 289 Digital Digital Multimeter True RMS, RSCAL Calibrated
- RS Stock No.:
- 218-371
- Mfr. Part No.:
- 3947801
- Brand:
- Fluke
Subtotal (1 unit)*
Kr. 11 097,40
(exc. VAT)
Kr. 13 871,75
(inc. VAT)
FREE delivery for online orders over 750,00 kr
In Stock
- 26 unit(s) ready to ship
- Plus 17 unit(s) shipping from 04 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | Kr. 11 097,40 |
*price indicative
- RS Stock No.:
- 218-371
- Mfr. Part No.:
- 3947801
- Brand:
- Fluke
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Fluke | |
| Product Type | Multimeter | |
| Multimeter Type | Digital | |
| Model Number | 289 | |
| Display Type | Digital | |
| Resistance Resolution | 10mΩ | |
| Functions Measured | AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Resistance, Temperature | |
| Maximum DC Voltage Measurement | 1kV dc | |
| True RMS | Yes | |
| DC Current Accuracy | ± 0.05 % | |
| AC Current Accuracy | ± 0.6 % | |
| DC Voltage Accuracy | 0.025 % | |
| AC Voltage Accuracy | ± 0.4 % | |
| DC Current Resolution | 0.01μA dc | |
| AC Current Resolution | 0.01μA ac | |
| DC Voltage Resolution | 1 μV dc | |
| Maximum Frequency | 100kHz | |
| Minimum Operating Temperature | -20°C | |
| Resistance Measurement Accuracy | ±0.05 % rdg + 2 Digits | |
| Battery Life | 200h | |
| Maximum Operating Temperature | 55°C | |
| Height | 222mm | |
| Standards/Approvals | No | |
| Weight | 870.9g | |
| Width | 102mm | |
| Length | 60mm | |
| Safety Category Level | CAT III, CAT IV | |
| Safety Category Voltage | 1000V | |
| Calibrated | RSCAL | |
| Battery Type | AA x 6 | |
| Select all | ||
|---|---|---|
Brand Fluke | ||
Product Type Multimeter | ||
Multimeter Type Digital | ||
Model Number 289 | ||
Display Type Digital | ||
Resistance Resolution 10mΩ | ||
Functions Measured AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Resistance, Temperature | ||
Maximum DC Voltage Measurement 1kV dc | ||
True RMS Yes | ||
DC Current Accuracy ± 0.05 % | ||
AC Current Accuracy ± 0.6 % | ||
DC Voltage Accuracy 0.025 % | ||
AC Voltage Accuracy ± 0.4 % | ||
DC Current Resolution 0.01μA dc | ||
AC Current Resolution 0.01μA ac | ||
DC Voltage Resolution 1 μV dc | ||
Maximum Frequency 100kHz | ||
Minimum Operating Temperature -20°C | ||
Resistance Measurement Accuracy ±0.05 % rdg + 2 Digits | ||
Battery Life 200h | ||
Maximum Operating Temperature 55°C | ||
Height 222mm | ||
Standards/Approvals No | ||
Weight 870.9g | ||
Width 102mm | ||
Length 60mm | ||
Safety Category Level CAT III, CAT IV | ||
Safety Category Voltage 1000V | ||
Calibrated RSCAL | ||
Battery Type AA x 6 | ||
RoHS Status: Exempted
- COO (Country of Origin):
- US
Fluke Multimeter, 0.025% DC Voltage Accuracy, 0.6% AC Current Accuracy - FLUKE 289/EUR
This multimeter is a handheld industrial logging instrument designed for diagnosing electrical, electronic and electro‑mechanical systems. It records and graphically displays measured data on‑screen for unattended monitoring and Rapid fault analysis, while offering true‑rms measurement capability for complex signals and selectable filtering to handle electrically noisy environments.
Features & Benefits
• True‑rms measurement to 100kHz for accurate non‑linear signals
• High‑accuracy DC voltage performance at 0.025% for precision tasks
• AC current measurement with 0.6% accuracy for load verification
• Logging memory up to 15,000 readings for extended unattended monitoring
• Peak capture to 250μs to reveal fast transients during troubleshooting
• LoZ volts and low‑pass filter to eliminate ghost voltages and noise
• High‑accuracy DC voltage performance at 0.025% for precision tasks
• AC current measurement with 0.6% accuracy for load verification
• Logging memory up to 15,000 readings for extended unattended monitoring
• Peak capture to 250μs to reveal fast transients during troubleshooting
• LoZ volts and low‑pass filter to eliminate ghost voltages and noise
**Applications**
• Suitable for fault diagnosis on adjustable‑speed motor drives
• Ideal for power distribution and plant automation maintenance
• Used for resistance comparison in motor winding and contact testing
• Can be used for logging trends in electro‑mechanical equipment
• Used with current clamps for high‑current monitoring and analysis
• Ideal for power distribution and plant automation maintenance
• Used for resistance comparison in motor winding and contact testing
• Can be used for logging trends in electro‑mechanical equipment
• Used with current clamps for high‑current monitoring and analysis
How is timing information associated with recorded measurements?
A real‑time clock stamps each saved reading so logged data include precise time references.
What power source and endurance does the instrument provide in the field?
It runs on six AA batteries and can deliver around 200 hours in logging mode under specified conditions.
How can logged sessions be reviewed without a PC?
On‑board TrendCapture graphically displays logged sessions and includes a zoom function to inspect events up to 14x closer.
What connectivity options exist for transferring data to a computer?
An optically isolated communications port enables safe data transfer to a PC when used with the appropriate cable and software.
What measurement ranges support low‑ohm and capacitance testing?
A two‑terminal 50Ω range with 1mΩ resolution and a 100mF capacitance range allow fine low‑ohm and high‑capacitance assessments.
Supplied with
The Fluke 289 comes with:
Manual
6 x AA Batteries
Installed TL71 Silicone Test Leads
Probe Holder
2 x AC72 Alligator Clips
Manual
6 x AA Batteries
Installed TL71 Silicone Test Leads
Probe Holder
2 x AC72 Alligator Clips
