WAGO 745 Series PCB Connector, 8-Contact, 5 mm Pitch, Through Hole, 1 Row
- RS Stock No.:
- 222-472
- Mfr. Part No.:
- 745-108
- Brand:
- WAGO
Subtotal (1 box of 60 units)*
Kr. 3 521,23
(exc. VAT)
Kr. 4 401,54
(inc. VAT)
Stock information currently inaccessible - Please check back later
Box(es) | Per Box | Per unit* |
|---|---|---|
| 1 + | Kr. 3 521,23 | Kr. 58,687 |
*price indicative
- RS Stock No.:
- 222-472
- Mfr. Part No.:
- 745-108
- Brand:
- WAGO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | WAGO | |
| Number of Contacts | 8 | |
| Product Type | PCB Connector | |
| Pitch | 5mm | |
| Number of Rows | 1 | |
| Current | 32A | |
| Housing Material | Polyamide 66 | |
| Mount Type | Through Hole | |
| Minimum Wire Size mm² | 0.08mm² | |
| Maximum Wire Size mm² | 4mm² | |
| Minimum Wire Size AWG | 28AWG | |
| Maximum Wire Size AWG | 12AWG | |
| Wire Connection Method | Cage Clamp | |
| Colour | Grey | |
| Voltage | 32V | |
| Standards/Approvals | No | |
| Depth | 22.9mm | |
| Width | 41.5mm | |
| Series | 745 | |
| Select all | ||
|---|---|---|
Brand WAGO | ||
Number of Contacts 8 | ||
Product Type PCB Connector | ||
Pitch 5mm | ||
Number of Rows 1 | ||
Current 32A | ||
Housing Material Polyamide 66 | ||
Mount Type Through Hole | ||
Minimum Wire Size mm² 0.08mm² | ||
Maximum Wire Size mm² 4mm² | ||
Minimum Wire Size AWG 28AWG | ||
Maximum Wire Size AWG 12AWG | ||
Wire Connection Method Cage Clamp | ||
Colour Grey | ||
Voltage 32V | ||
Standards/Approvals No | ||
Depth 22.9mm | ||
Width 41.5mm | ||
Series 745 | ||
The Wago PCB terminal block is engineered for seamless integration into a variety of electronic applications. With its robust design and reliable CAGE CLAMP connection technology, this product stands out for its mechanical stability and versatility. Ideal for commoning and distributing potentials, the terminal block caters to different conductor types while maintaining a compact footprint.
Includes an integrated testing tap for convenient testing procedures
Offers a pin spacing of only 5 mm ensuring space efficiency
Available in multiple configurations for diverse applications
Constructed with flame retardant materials for safety
