WAGO 2636 Series PCB Connector, 4-Contact, 10 mm Pitch, Feed Through, 1 Row
- RS Stock No.:
- 225-222
- Mfr. Part No.:
- 2636-3104/020-000
- Brand:
- WAGO
Subtotal (1 box of 25 units)*
Kr. 3 357,64
(exc. VAT)
Kr. 4 197,05
(inc. VAT)
FREE delivery for online orders over 750,00 kr
Temporarily out of stock
- Shipping from 23 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Box(es) | Per Box | Per unit* |
|---|---|---|
| 1 + | Kr. 3 357,64 | Kr. 134,306 |
*price indicative
- RS Stock No.:
- 225-222
- Mfr. Part No.:
- 2636-3104/020-000
- Brand:
- WAGO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | WAGO | |
| Product Type | PCB Connector | |
| Number of Contacts | 4 | |
| Pitch | 10mm | |
| Current | 76A | |
| Number of Rows | 1 | |
| Housing Material | Polyamide 66 | |
| Minimum Wire Size mm² | 0.75mm² | |
| Mount Type | Feed Through | |
| Maximum Wire Size mm² | 25mm² | |
| Minimum Wire Size AWG | 18AWG | |
| Maximum Wire Size AWG | 4AWG | |
| Orientation | 90° | |
| Colour | Grey | |
| Wire Connection Method | Push-in | |
| Voltage | 1000V | |
| Depth | 24.8mm | |
| Width | 41.6mm | |
| Series | 2636 | |
| Standards/Approvals | No | |
| Select all | ||
|---|---|---|
Brand WAGO | ||
Product Type PCB Connector | ||
Number of Contacts 4 | ||
Pitch 10mm | ||
Current 76A | ||
Number of Rows 1 | ||
Housing Material Polyamide 66 | ||
Minimum Wire Size mm² 0.75mm² | ||
Mount Type Feed Through | ||
Maximum Wire Size mm² 25mm² | ||
Minimum Wire Size AWG 18AWG | ||
Maximum Wire Size AWG 4AWG | ||
Orientation 90° | ||
Colour Grey | ||
Wire Connection Method Push-in | ||
Voltage 1000V | ||
Depth 24.8mm | ||
Width 41.6mm | ||
Series 2636 | ||
Standards/Approvals No | ||
The Wago PCB terminal block seamlessly integrates functionality and versatility for your electrical applications. Designed with a push-in CAGE CLAMP technology, it ensures secure connections for solid and fine-stranded conductors alike, making it ideal for panel feedthrough configurations. This component accommodates electrical demands with impressive ratings for both voltage and current, whilst maintaining compliance with top industry standards like IEC and UL.
Manufactured with high quality materials for enhanced durability
Supports a broad temperature range to meet diverse environmental requirements
Complies with strict regulations ensuring safety and reliability
