Phoenix Contact, 5.08mm Pitch, MSTB 2.5/ 6-ST-5.08 BD:1-6, 6 Way, , Pluggable Terminal Block, Plug, Plug-In, Screw

A range of Classic COMBICON MSTB 5.08 mm pitch plug-in cable mount terminal block connectors from Phoenix Contact. The user-friendly PCB terminals feature a 0.2 mm² to 2.5 mm² screw connection that forms a standard plug-in system for 320 V (III/2).

• Secure screw connection
• Well-known connection principle allows you to use worldwide
• Maximum contact force gives low temperature rise
• Long service life

Use this terminal block from Phoenix Contact to make convenient connections to your PCB (printed circuit board). The unit has 6 contacts, which let you connect multiple cables to your electrical system at the same time. These contacts are made of highly conductive copper-alloy material to ensure a reliable connection. For enhanced durability, the block has a polyamide (PA) housing that's resistant to impact. This material also serves as an effective insulator, protecting you from electric shocks.
Thanks to its wide operating temperature range of -40°C to +100°C, you can rely on this terminal block for safe use in harsh environments. Its compact dimensions of 18.3 (length) x 30.48 (width) x 15mm (height) make it a good choice for setups with limited space. You'll commonly find this component used in the automation industry.

• IP (ingress protection) rating of IP20 to withstand dust and objects larger than 12mm in size
• Screw termination method for quick and simple installation
• UL 94-V0 rating means that burning stops within 10 seconds for fire safety
