Weidmüller SV Series PCB Connector, 5-Contact, 7.62 mm Pitch, 1 Row, 1930300000
- RS Stock No.:
- 176-7728
- Mfr. Part No.:
- 1930300000
- Brand:
- Weidmüller
Bulk discount available
View bulk pricing optionsSubtotal (1 box of 48 units)*
Kr. 2 358,576
(exc. VAT)
Kr. 2 948,208
(inc. VAT)
FREE delivery for online orders over 750,00 kr
Temporarily out of stock
- Shipping from 24 July 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Box* |
|---|---|---|
| 48 - 192 | Kr. 49,137 | Kr. 2 358,58 |
| 240 - 432 | Kr. 46,091 | Kr. 2 212,37 |
| 480 + | Kr. 43,339 | Kr. 2 080,27 |
*price indicative
- RS Stock No.:
- 176-7728
- Mfr. Part No.:
- 1930300000
- Brand:
- Weidmüller
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Weidmüller | |
| Number of Contacts | 5 | |
| Product Type | PCB Connector | |
| Pitch | 7.62mm | |
| Number of Rows | 1 | |
| Current | 35A | |
| Housing Material | Copper Alloy, Polyamide Fibreglass | |
| Connector Gender | Male | |
| Orientation | Straight | |
| Colour | Black | |
| Wire Connection Method | Solder | |
| Voltage | 1kV | |
| Length | 35.48mm | |
| Depth | 11.4mm | |
| Standards/Approvals | No | |
| Series | SV | |
| Width | 28.3mm | |
| Select all | ||
|---|---|---|
Brand Weidmüller | ||
Number of Contacts 5 | ||
Product Type PCB Connector | ||
Pitch 7.62mm | ||
Number of Rows 1 | ||
Current 35A | ||
Housing Material Copper Alloy, Polyamide Fibreglass | ||
Connector Gender Male | ||
Orientation Straight | ||
Colour Black | ||
Wire Connection Method Solder | ||
Voltage 1kV | ||
Length 35.48mm | ||
Depth 11.4mm | ||
Standards/Approvals No | ||
Series SV | ||
Width 28.3mm | ||
- COO (Country of Origin):
- RO
Male header in 90° outlet direction for 400 V TNC (S) systems. The mating profile ensures touch-safety of more than 3 mm. Maximum operational reliability: with a derating up to 125 °C, a mating profile that can only be plugged in correct, unique coding capability and additional fastening mechanism.
Available with a flange (F), screw flange (SF) and clip on screw flange (SFC)
