PTR HARTMANN AKZ1550 Series Pluggable Terminal Block, 5-Contact, 3.81 mm Pitch, 1 Row, AKZ1550/05-3.81
- RS Stock No.:
- 285-7168
- Distrelec Article No.:
- 148-41-213
- Mfr. Part No.:
- AKZ1550/05-3.81
- Brand:
- PTR HARTMANN
Subtotal (1 unit)*
Kr. 25,98
(exc. VAT)
Kr. 32,48
(inc. VAT)
FREE delivery for online orders over 750,00 kr
Being discontinued
- Final 158 unit(s), ready to ship from another location
Units | Per unit |
|---|---|
| 1 + | Kr. 25,98 |
*price indicative
- RS Stock No.:
- 285-7168
- Distrelec Article No.:
- 148-41-213
- Mfr. Part No.:
- AKZ1550/05-3.81
- Brand:
- PTR HARTMANN
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | PTR HARTMANN | |
| Product Type | Pluggable Terminal Block | |
| Number of Contacts | 5 | |
| Pitch | 3.81mm | |
| Current | 8A | |
| Number of Rows | 1 | |
| Minimum Wire Size mm² | 1.5mm² | |
| Connector Gender | Female | |
| Maximum Wire Size mm² | 0.5mm² | |
| Minimum Wire Size AWG | 16AWG | |
| Maximum Wire Size AWG | 28AWG | |
| Orientation | Straight | |
| Wire Connection Method | Screw | |
| Colour | Green | |
| Voltage | 300V | |
| Series | AKZ1550 | |
| Standards/Approvals | RoHS | |
| Select all | ||
|---|---|---|
Brand PTR HARTMANN | ||
Product Type Pluggable Terminal Block | ||
Number of Contacts 5 | ||
Pitch 3.81mm | ||
Current 8A | ||
Number of Rows 1 | ||
Minimum Wire Size mm² 1.5mm² | ||
Connector Gender Female | ||
Maximum Wire Size mm² 0.5mm² | ||
Minimum Wire Size AWG 16AWG | ||
Maximum Wire Size AWG 28AWG | ||
Orientation Straight | ||
Wire Connection Method Screw | ||
Colour Green | ||
Voltage 300V | ||
Series AKZ1550 | ||
Standards/Approvals RoHS | ||
- COO (Country of Origin):
- DE
The Straight Female header with 3.81 mm Pitch. It has 5 pole and Combustibility Class of UL 94 V-0.
VDE approved
cURus approved
