RS PRO 2 Core Power Cable, 16 mm² Armoured PVC Sheath, 1000, 600 V
- RS Stock No.:
- 185-3997
- Brand:
- RS PRO
1 In stock for same day dispatch
Added
Price 1 Reel of 100 Metre(s)
Kr. 14 105,41
(exc. VAT)
Kr. 17 631,76
(inc. VAT)
| Reel(s) | Per Reel | Per Metre* |
| 1 + | Kr. 14 105,41 | Kr. 141,054 |
| *price indicative | ||
- RS Stock No.:
- 185-3997
- Brand:
- RS PRO
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- GB
Product Details
RS PRO Armoured Cable
The RS PRO 2-core armoured cable has an outer diameter of 20mm and has galvanised steel wire armour (SWA) construction. This multicore cable is polyvinyl chloride (PVC) type 9 sheathed and has a copper conductor. The nominal cross-sectional area of the conductor is 16mm² and has a voltage rating of 1kV, 600V. These cables are designed to be installed in air, clipped to surface, on cable tray/ladder work, embedded in concrete and buried direct or in the ducting underground.
Features and Benefits
• Insulation material is thermosetting XLPE Type GP8
• Minimum bend radius of 8
• Operating temperature between -15°C and 90°C
• Minimum bend radius of 8
• Operating temperature between -15°C and 90°C
Applications
• Industrial wiring
• Mains distribution
• Mains distribution
Certifications
• BS EN 60228
• BS 7655-1.3
• BS 7655-4.2
• BS 7655-1.3
• BS 7655-4.2
Specifications
Attribute | Value |
|---|---|
| Cross Sectional Area | 16 mm² |
| Number of Cores | 2 |
| Armoured | Yes |
| CPR Certification | Eca |
| Outer Diameter | 20mm |
| Sheath Material | PVC |
| Voltage Rating | 1000, 600 V |
| Conductor Strand Type | Stranded |
| Minimum Operating Temperature | -15°C |
| Size of Strands | 1.70 mm |
| Conductor Material | Copper |
| Insulation Material | XLPE |
| American Wire Gauge | 5 AWG |
| Core Strands | 7/1.70 mm |
| Cable Shape | Multicore |
| Maximum Operating Temperature | +90°C |
| Standards Met | BS EN 60228 |
