RS PRO, TRS, 100m 4 Core, Black CPE Power Cable +60°C

RS Stock No.:: 863-4024
Brand:: RS PRO

RS PRO, TRS, 100m 4 Core, Black CPE Power Cable +60°C

1 / 4

Subtotal (1 reel of 100 metres)**

Kr. 3 753,92

(exc. VAT)

Kr. 4 692,40

(inc. VAT)

1 In stock for same day dispatch*

* Delivery dates may change based on your chosen quantity and delivery address.

FREE delivery for orders over kr 500,00

Check stock levels

Reel(s)	Per Reel	Per Metre**
1 +	Kr. 3 753,92	Kr. 37,539

**price indicative

RS Stock No.:: 863-4024
Brand:: RS PRO

RS PRO H05RR-F Harmonised Rubber Insulated Mains Cable

From RS PRO a high-quality, durable and lightweight H05RR-F harmonised flexible mains power cable with rubber insulation and outer jacket. This power cable has a voltage rating of 300 to 500 V and is ideal for providing power to small portable domestic and industrial appliances.

What is Mains Cable?

A mains power cable connects an appliance to a mains electricity supply through the use of a wall socket or an extension lead which will then be plugged into a mains supply.

Cable Construction

This flexible cable consists of cores made up of bare stranded copper conductors or wires. Each individual core is surrounded by colour coded rubber insulation for easy identification of the wires. All the cores are then surrounded by a final layer of rubber called a sheath or jacket.

What Does H05RR-F Mean?

H05RR-F flexible cable is a type of harmonised cable which means it belongs to the Harmonised Reference System and conforms to the European Harmonisation Standard. This purpose of this standard is to improve standards and quality of cables across Europe to ensure the trade of common standard product.

H05RR-F is the code for this harmonised cable which breaks down into the following:

• H = Harmonised
• 05 = 300 / 500 voltage rating
• R = Natural or synthetic rubber insulation
• R = Natural or synthetic rubber sheath
• F = Flexible copper conductors

Features and Benefits

• Flexible, even at low temperatures
• Excellent resistance to tear and fatigue
• High resistance to abrasion
• Good tensile strength
• Good resistance to dilute acids and bases
• Excellent water resistance

Where are These Cables Used?

Rubber insulated mains power cables are ideal for use in fixed installations and providing mains power to portable appliances in both domestic premises, kitchens and offices. These cables are designed for use in applications in dry and damp locations where minimal damage and a low degree of stress is expected. Applications include the following:

• Household and kitchen appliances such as irons, vacuum cleaners and toasters
• Handheld and portable devices such as radios
• Office equipment such as air conditioning fans
• Lightweight hand and workshop tools such as soldering irons
• Suitable for fixed installation in partition walls, furniture and in hollow spaces of prefabricated building parts

Standards

BS EN 60228, BS EN 50363, RoHS, CE, VDE 0282, VDE 0472, GB/T5013

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	RS PRO
	Cross Sectional Area	1.5 mm²
	Number of Cores	4
	Sheath Colour	Black
	Length	100m
	Cable Type	TRS
	Current Rating	16 A
	CPR Certification	Eca
	Outer Diameter	9.5 → 9.9mm
	Sheath Material	CPE
	Voltage Rating	300 V, 500 V
	European Harmonised Code	H05RR-F
	Conductor Strand Type	Stranded
	Number of Strands	30
	American Wire Gauge	15 AWG
	Conductor Resistance	13.3 Ω/km
	Insulation Material	EPDM
	Standards Met	Euroclass Eca
	Size of Strands	0.24 mm
	Maximum Operating Temperature	+60°C
	Minimum Operating Temperature	-25°C
	Conductor Material	Copper
	Core Strands	30/0.24 mm

	Select all
	Brand RS PRO
	Cross Sectional Area 1.5 mm²
	Number of Cores 4
	Sheath Colour Black
	Length 100m
	Cable Type TRS
	Current Rating 16 A
	CPR Certification Eca
	Outer Diameter 9.5 → 9.9mm
	Sheath Material CPE
	Voltage Rating 300 V, 500 V
	European Harmonised Code H05RR-F
	Conductor Strand Type Stranded
	Number of Strands 30
	American Wire Gauge 15 AWG
	Conductor Resistance 13.3 Ω/km
	Insulation Material EPDM
	Standards Met Euroclass Eca
	Size of Strands 0.24 mm
	Maximum Operating Temperature +60°C
	Minimum Operating Temperature -25°C
	Conductor Material Copper
	Core Strands 30/0.24 mm
