APEM Toggle Switch, Panel Mount, On-Off, DPDT, Solder Terminal
- RS Stock No.:
- 224-108
- Mfr. Part No.:
- 641H/2-5
- Brand:
- APEM
View all Toggle Switches
45 In stock for same day dispatch
Price Each
kr 178,29
(exc. VAT)
kr 222,86
(inc. VAT)
| Units | Per unit |
| 1 - 24 | kr 178,29 |
| 25 - 49 | kr 146,43 |
| 50 - 99 | kr 133,67 |
| 100 - 249 | kr 124,72 |
| 250 + | kr 113,87 |
- RS Stock No.:
- 224-108
- Mfr. Part No.:
- 641H/2-5
- Brand:
- APEM
- COO (Country of Origin):
- FR
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- FR
Product Details
Industrial Toggle Switch, 600H series
From Apem, this industrial toggle switch features a 40mm lever actuator that can be used with joystick-type sealing caps. With a 12mm bushing, this Apem switch boasts an ergonomic design and has contacts resistance welded to the terminal for increased durability.
The front face of this 600H Series toggle switch is fully insulated and sealed, meaning it is ideal for use in industrial environments.
The front face of this 600H Series toggle switch is fully insulated and sealed, meaning it is ideal for use in industrial environments.
Features and Benefits:
• Long lever
• ø 12 mm bushing
• Robust design
• ø 12 mm bushing
• Robust design
Specifications
| Attribute | Value |
| Contact Configuration | DPDT |
| Switch Operation | On-Off |
| Contact Current Rating | 10 A @ 24 V dc |
| Mounting Type | Panel Mount |
| Terminal Type | Solder |
| Panel Cut Out Diameter | 12.5mm |
| Actuator Length | 40mm |
| Actuator Material | Nickel Plated Brass |
| Contact Material | Silver Nickel Alloy |
| Panel Cut Out Size | 12.5mm |
| Contact Resistance | 0.01Ω |
| Maximum Operating Temperature | +55°C |
| Mechanical Life | 10000Operations |
| Operating Temperature Range | -20 → +55°C |
| Minimum Operating Temperature | -20°C |
