onsemi, Logic Level Translator Translator 3 LVCMOS, CML, LVTTL to LVPECL, LVDS, ECL, 16-Pin QFN
- RS Stock No.:
- 124-5341
- Mfr. Part No.:
- NB4L52MNG
- Brand:
- onsemi
Subtotal (1 tube of 123 units)*
Kr. 16 800,693
(exc. VAT)
Kr. 21 000,897
(inc. VAT)
FREE delivery for online orders over 500,00 kr
Temporarily out of stock
- Shipping from 10. august 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tube* |
|---|---|---|
| 123 + | Kr. 136,591 | Kr. 16 800,69 |
*price indicative
- RS Stock No.:
- 124-5341
- Mfr. Part No.:
- NB4L52MNG
- Brand:
- onsemi
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | onsemi | |
| Logic Family | LVPECL | |
| Direction Type | Uni-Directional | |
| Product Type | Logic Level Translator | |
| Maximum Propagation Delay Time @ CL | 500ps | |
| Mount Type | Surface | |
| Number of Elements per Chip | 3 | |
| Package Type | QFN | |
| Output Type | LVPECL | |
| Pin Count | 16 | |
| Logic Function | Translator | |
| Maximum Low Level Output Current | 25mA | |
| Maximum High Level Output Current | -25mA | |
| Minimum Supply Voltage | 2.375V | |
| Translation | LVCMOS, CML, LVTTL to LVPECL, LVDS, ECL | |
| Maximum Supply Voltage | 5.5V | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 85°C | |
| Standards/Approvals | No | |
| Length | 3mm | |
| Height | 0.95mm | |
| Series | NB4L52MNG | |
| Width | 3 mm | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand onsemi | ||
Logic Family LVPECL | ||
Direction Type Uni-Directional | ||
Product Type Logic Level Translator | ||
Maximum Propagation Delay Time @ CL 500ps | ||
Mount Type Surface | ||
Number of Elements per Chip 3 | ||
Package Type QFN | ||
Output Type LVPECL | ||
Pin Count 16 | ||
Logic Function Translator | ||
Maximum Low Level Output Current 25mA | ||
Maximum High Level Output Current -25mA | ||
Minimum Supply Voltage 2.375V | ||
Translation LVCMOS, CML, LVTTL to LVPECL, LVDS, ECL | ||
Maximum Supply Voltage 5.5V | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 85°C | ||
Standards/Approvals No | ||
Length 3mm | ||
Height 0.95mm | ||
Series NB4L52MNG | ||
Width 3 mm | ||
Automotive Standard No | ||
- COO (Country of Origin):
- TH
