Texas Instruments, Voltage Level Translator Level Shifter 1 Level Shifting, 48-Pin TSSOP
- RS Stock No.:
- 226-4892
- Mfr. Part No.:
- SN74ALVC164245DGGR
- Brand:
- Texas Instruments
Subtotal (1 reel of 2000 units)*
Kr. 45 796,00
(exc. VAT)
Kr. 57 244,00
(inc. VAT)
FREE delivery for online orders over 500,00 kr
Temporarily out of stock
- 2 000 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
|---|---|---|
| 2000 + | Kr. 22,898 | Kr. 45 796,00 |
*price indicative
- RS Stock No.:
- 226-4892
- Mfr. Part No.:
- SN74ALVC164245DGGR
- Brand:
- Texas Instruments
Specifications
Legislation and Compliance
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Texas Instruments | |
| Product Type | Voltage Level Translator | |
| Logic Family | ALVC | |
| Direction Type | Bi-Directional | |
| Maximum Propagation Delay Time @ CL | 5.8ns | |
| Mount Type | Surface | |
| Package Type | TSSOP | |
| Number of Elements per Chip | 1 | |
| Output Type | 3 State | |
| Pin Count | 48 | |
| Logic Function | Level Shifter | |
| Maximum Low Level Output Current | 24mA | |
| Maximum High Level Output Current | -24mA | |
| Minimum Supply Voltage | -0.5V | |
| Maximum Supply Voltage | 4.6V | |
| Translation | Level Shifting | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 85°C | |
| Width | 8.3 mm | |
| Length | 12.6mm | |
| Series | SN74ALVC164245 | |
| Standards/Approvals | No | |
| Height | 1.2mm | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand Texas Instruments | ||
Product Type Voltage Level Translator | ||
Logic Family ALVC | ||
Direction Type Bi-Directional | ||
Maximum Propagation Delay Time @ CL 5.8ns | ||
Mount Type Surface | ||
Package Type TSSOP | ||
Number of Elements per Chip 1 | ||
Output Type 3 State | ||
Pin Count 48 | ||
Logic Function Level Shifter | ||
Maximum Low Level Output Current 24mA | ||
Maximum High Level Output Current -24mA | ||
Minimum Supply Voltage -0.5V | ||
Maximum Supply Voltage 4.6V | ||
Translation Level Shifting | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 85°C | ||
Width 8.3 mm | ||
Length 12.6mm | ||
Series SN74ALVC164245 | ||
Standards/Approvals No | ||
Height 1.2mm | ||
Automotive Standard No | ||
