RS PRO 3 → 6V -400/1000 mBar Direct Coupling Gas Compressor Pump Water Pump, 0.4L/min
- RS Stock No.:
- 817-0716
- Brand:
- RS PRO
7 In stock for same day dispatch
Added
Price Each
Kr. 1 329,13
(exc. VAT)
Kr. 1 661,41
(inc. VAT)
| Units | Per unit |
| 1 + | Kr. 1 329,13 |
- RS Stock No.:
- 817-0716
- Brand:
- RS PRO
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- GB
Product Details
RS PRO Gas and Liquid Micro Pump (0.4l/min)
A reliable and high-performance micro pump that is suitable for use in a wide range of applications including medical devices, laboratory equipment, and chemical processing.
A hardwearing and tough micro pump constructed from Glass Filled Nylon with Stainless Steel tubing connectors and fitted with a Nitrile I Silicon diaphragm and valves with simple and quick push fit connectors, designed for 2.4mm bore flexible tubing.
Ideal for applications that require a high level of reliability and precision with a flow rate of up to 620 ml/min and a pressure of up to 12 psi. The compact lightweight design is highly suited to installation in cramp and small spaces or portable appliances where space is at a premium.
Featuring a brushless motor for high performance, extended product life and a low noise pump with a noise level of <15dB making the micro pump perfect for use in devices in laboratories, schools and public environments where noise levels need to be restricted.
The micro pump is customisable, and the head can be realigned to one of 4 different positions for easy tube connections.
A precise and reliable pump resistant to a wide range of chemicals and suitable for use in multitude of applications and environments. These include medical devices, analysis systems, gas detection and monitoring, cooling systems, precision flow applications and battery and solar operated systems.
Features and Benefits
Gas and liquid micro pump
Brushless design
Low noise level
Resistant to a wide range of chemicals and fluids
Variable flow rate and power consumption
Compact size of 42 x 27 x 17 mm
Usable with solar power, PSU or batteries
Operating Temp -20 to 100 C
IP41 rated
Noise Levels <15dB
Brushless design
Low noise level
Resistant to a wide range of chemicals and fluids
Variable flow rate and power consumption
Compact size of 42 x 27 x 17 mm
Usable with solar power, PSU or batteries
Operating Temp -20 to 100 C
IP41 rated
Noise Levels <15dB
Why RS PRO?
RS PRO is the own brand of RS. The RS PRO Seal of Approval is your assurance of professional quality, a guarantee that every part is rigorously tested, inspected, and audited against demanding standards. Making RS PRO the Smart Choice for our customers.
Specifications
Attribute | Value |
|---|---|
| Maximum Flow Rate | 0.4L/min |
| Supply Voltage | 3 → 6V |
| Input Connection | 3.6mm Hose Barb |
| Maximum Working Pressure | -400/1000 mBar |
| Body Material | Anodised Aluminium |
| Coupling Type | Direct |
| Input Power | 0.8 → 1.1W (@ 6V) |
| Input Connection Size | 2.4mm |
| Output Connection Size | 2.4mm |
| Wetted Materials | Glass Filled Nylon (Tubing Connector), Silicone-Nitrile/EPDM/Viton (Seals) |
| Pump Type | Gas Compressor Pump |
| IP Rating | IP41 |
