Eaton DILM Contactor, 24V dc Coil, 3-Pole, 32 A, 15 kW 24V dc, 3 NO, 400V ac
- RS Stock No.:
- 866-1530
- Mfr. Part No.:
- 277306 DILM32-01(RDC24)
- Brand:
- Eaton
Subtotal (1 unit)*
Kr. 2 755,72
(exc. VAT)
Kr. 3 444,65
(inc. VAT)
FREE delivery for online orders over 750,00 kr
In Stock
- 2 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | Kr. 2 755,72 |
*price indicative
- RS Stock No.:
- 866-1530
- Mfr. Part No.:
- 277306 DILM32-01(RDC24)
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Product Type | Contactor | |
| Coil Voltage | 24V dc | |
| Number of Poles | 3 | |
| Contact Voltage | 400V ac | |
| Contact Current | 32A | |
| Series | DILM | |
| Power Rating | 15kW | |
| Function | Motor Control, Resistive Load | |
| Mount Type | Table | |
| Normal State Configuration | 3 NO | |
| Auxiliary Contact Configuration | 0 NO/1 NC | |
| Number of Auxiliary Contacts | 1 | |
| Terminal Type | Screw Clamp | |
| Operational Current Ie | 32A | |
| Control Circuit Voltage Uc | 24V dc | |
| Contactor Application | Motor Control, Resistive Load | |
| Minimum Operating Temperature | -25°C | |
| Maximum Operating Temperature | 50°C | |
| Standards/Approvals | CSA, IEC/EN 60947, UL, VDE 0660 | |
| Width | 45mm | |
| Depth | 98mm | |
| Length | 68mm | |
| Pole and Throw Configuration | 3 | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Product Type Contactor | ||
Coil Voltage 24V dc | ||
Number of Poles 3 | ||
Contact Voltage 400V ac | ||
Contact Current 32A | ||
Series DILM | ||
Power Rating 15kW | ||
Function Motor Control, Resistive Load | ||
Mount Type Table | ||
Normal State Configuration 3 NO | ||
Auxiliary Contact Configuration 0 NO/1 NC | ||
Number of Auxiliary Contacts 1 | ||
Terminal Type Screw Clamp | ||
Operational Current Ie 32A | ||
Control Circuit Voltage Uc 24V dc | ||
Contactor Application Motor Control, Resistive Load | ||
Minimum Operating Temperature -25°C | ||
Maximum Operating Temperature 50°C | ||
Standards/Approvals CSA, IEC/EN 60947, UL, VDE 0660 | ||
Width 45mm | ||
Depth 98mm | ||
Length 68mm | ||
Pole and Throw Configuration 3 | ||
Eaton Contactor, 400V AC Contact Voltage Rating, 68 (L) x 45 (W) x 97.4mm (D) - DILM Series - 277306 XTCE032C01TD
For swift switching with no snags, pick this 3-pole contactor from Eaton. It opens and closes circuits in high-current load systems so they can keep up with your industrial demands. Rapid shift capability and integrated suppressors help prevent damage. This means less time is spent on maintenance and productivity is boosted. You can control this unit directly from a PLC, which saves you from running up and down to make simple settings. As it's not a glutton for power, this instrument is an energy-efficient solution with a 15kW rating.
• Small size of 68 (L) x 45 (W) x 97.4mm (D) for easy installation in tight spaces
• Uniform accessories for convenient expansions or added protection
• Double box for reliable wiring of different cross-sections
• Wide operating temperature range between -25°C and +50°C for use in harsh conditions
What do A1 and A2 mean on a contactor?
These two indicators refer to the different ends of an electromagnetic coil assembly so you can connect the correct terminals to the designated power supplies.
How many auxiliary contacts does this contactor have?
It has one auxiliary contact, so it's simple to install.
Note
Eaton formerly known as Moeller
