Curtis Counter, 6 Digit, 12 → 48 V dc, 20 → 60 V ac
- RS Stock No.:
- 185-6006
- Brand:
- Curtis
163 In stock for same day dispatch
Added
Price Each
Kr. 550,00
(exc. VAT)
Kr. 687,50
(inc. VAT)
| Units | Per unit |
| 1 - 4 | Kr. 550,00 |
| 5 - 9 | Kr. 533,50 |
| 10 + | Kr. 511,50 |
- RS Stock No.:
- 185-6006
- Brand:
- Curtis
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
Solid State Hour Meter
Resettable
Count capacity 99999.9h
Count capacity 99999.9h
Curtis Hour Counter
The Curtis hour counter has a 6-digit LCD display, solid-state panel-mount type with a tab connection. It has a supply voltage rating ranges between 48VDC and 150VDC or 100VAC and 230VAC.
Features and Benefits
2-wire connection
Resettable
Case style is D shaped
Electrical reset method
Measurement ranges between 0 and 99999.9
Operation temperature ranges between : -40°C and 85°C
Resettable
Case style is D shaped
Electrical reset method
Measurement ranges between 0 and 99999.9
Operation temperature ranges between : -40°C and 85°C
Applications
Automobile industry
Marine application
Marine application
Certifications
IP65 rated
IP50 rated
CE certified
IP50 rated
CE certified
Specifications
Attribute | Value |
|---|---|
| Supply Voltage | 12 → 48 V dc, 20 → 60 V ac |
| Display Type | LCD |
| Input Type | Voltage |
| Connection Type | Tab |
| Reset Method | Electrical |
| Number of Digits | 6 |
| Mounting Type | Panel Mount |
| Digit Height | 5 mm |
| Backlighting | Yes |
| Display Range | 0 → 99999.9 |
| Minimum Operating Temperature | -40°C |
| Measurement Range | 0 → 99999.9 |
| Maximum Operating Temperature | +85°C |
