Rose Polyester Standard Series Grey Grey Lid Polyester Enclosure, IP66, IK08, 121 mm x 121 mm x 400 mm
- RS Stock No.:
- 254-5040
- Mfr. Part No.:
- 02254012
- Brand:
- Rose
Subtotal (1 unit)*
Kr. 5 385,97
(exc. VAT)
Kr. 6 732,46
(inc. VAT)
FREE delivery for online orders over 750,00 kr
In Stock
- Plus 1 unit(s) shipping from 12 October 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | Kr. 5 385,97 |
*price indicative
- RS Stock No.:
- 254-5040
- Mfr. Part No.:
- 02254012
- Brand:
- Rose
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Rose | |
| Body Material | Polyester | |
| Product Type | Enclosure | |
| External Height | 121mm | |
| External Width | 400mm | |
| External Length | 121mm | |
| IP Rating | IP66 | |
| Colour | Grey | |
| Lid Colour | Grey | |
| Flanged | No | |
| Hazardous Area Certification | No | |
| Mounting plate | Yes | |
| Series | Polyester Standard | |
| Number of Knockouts | 0 | |
| Weight | 3713g | |
| Standards/Approvals | UL 508a | |
| IK Rating | IK08 | |
| Transparent Door | No | |
| Gasket Material | Cr (Chloroprene) | |
| Select all | ||
|---|---|---|
Brand Rose | ||
Body Material Polyester | ||
Product Type Enclosure | ||
External Height 121mm | ||
External Width 400mm | ||
External Length 121mm | ||
IP Rating IP66 | ||
Colour Grey | ||
Lid Colour Grey | ||
Flanged No | ||
Hazardous Area Certification No | ||
Mounting plate Yes | ||
Series Polyester Standard | ||
Number of Knockouts 0 | ||
Weight 3713g | ||
Standards/Approvals UL 508a | ||
IK Rating IK08 | ||
Transparent Door No | ||
Gasket Material Cr (Chloroprene) | ||
- COO (Country of Origin):
- DE
The Rose polyester enclosure having height is 250 mm, width is 400 mm and depth is 121 mm. The enclosure are made from polyster. The color of the product is Squirrel Gray (RAL 7000). Special colors also available as per customer demands. And the product are fully insulated according to VDE 0100.
Height is 150 mm
Width is 400 mm
Depth is 121 mm
Minium temperature are is -40 °C
Maximum temperature is 90 °C
Toxicity is aalogen free
Surface resistance are >10^12 Ohm
