Flowline US03 Series Reflective Ultrasonic Liquid Level Transmitter Level Transmitter, Horizontal, Vertical, Housing

View all Level Sensors

Subtotal (1 unit)*

Kr. 9 986,89

(exc. VAT)

Kr. 12 483,61

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 1 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 +Kr. 9 986,89

*price indicative

RS Stock No.:
137-2045
Mfr. Part No.:
US03-0001-01
Brand:
Flowline
Find similar products by selecting one or more attributes.
Select all

Brand

Flowline

Product Type

Level Transmitter

Device Type

Reflective Ultrasonic Liquid Level Transmitter

Mount Type

Horizontal, Vertical

Housing Material

Polypropylene

Cable Length

1.2m

Minimum Operating Temperature

-40°C

Interface Type

USB

Maximum Operating Temperature

80°C

Maximum DC Voltage

28V dc

Maximum Current

20mA

Maximum Pressure

2bar

Standards/Approvals

CE, CSA, cUS

Hazardous Area Certification

No

Series

US03

RoHS Status: Not Applicable

COO (Country of Origin):
US

Flowline EchoTouch US01 & US03 Reflective Ultrasonic Liquid Level Transmitter


Flowline EchoTouch US01 & US03 intrinsically safe reflective ultrasonic level transmitter provides continuous level measurement up to 3 m with a 4 mA to 20 mA analogue signal output configurable via Flowline WebCal software. The non-contact liquid level sensor features proprietary Reflective Technology that delivers reliable level measurement in condensing environments. Typical applications include day tank, IBC or drum, cooling tower, skid or machine, process tank and waste sumps.

Features and Benefits


Reflective Technology measures reliably with condensation;Narrow 2” (5 cm) beam width for applications with limited space;Configuration is easy with WebCal software and USB adapter;Short 1.5” (3.8 cm) dead band maximises tank filling capacity;PVDF transducer and PP enclosure for corrosive environments;Fail-safe diagnostics with selectable fail-safe signal outputs;Type 6P (IP68) compact enclosure for small tank applications;Automatic temperature compensation from -40º to 80º C.
