Unavailable
RS will no longer stock this product.
Alternative
This product is not currently available. Here is our alternative recommendation.
Each
Kr. 1 796,46
(exc. VAT)
Kr. 2 245,58
(inc. VAT)
- RS Stock No.:
- 176-2124
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Product Type | Pneumatic Solenoid Valve | |
| Port Size | 1/2 in | |
| Connection Thread Standard | G | |
| Actuation Type | Solenoid | |
| Seal Material | Nitrile Rubber (NBR) | |
| Series | 01V | |
| Solenoid Type | Single | |
| Mount Type | Base | |
| Number of Ports | 5 | |
| Body Material | Aluminium | |
| Maximum Operating Pressure | 10 bar | |
| Minimum Operating Temperature | -10°C | |
| Maximum Pilot Pressure | 10bar | |
| Port Gender | Female | |
| Minimum Pilot Pressure | 1bar | |
| Maximum Flow Rate | 5000NL/min | |
| Valve Function | 5/3 PC | |
| Maximum Operating Temperature | 60°C | |
| Solenoid Power Consumption | 2W | |
| Length | 275.2mm | |
| Width | 30mm | |
| Hazardous Area Certification | ATEX | |
| Standards/Approvals | RoHS, REACH | |
| Height | 60mm | |
| Electrical Connection Type | Plug Socket | |
| Number of Positions | 1 | |
| Select all | ||
|---|---|---|
Brand RS PRO | ||
Product Type Pneumatic Solenoid Valve | ||
Port Size 1/2 in | ||
Connection Thread Standard G | ||
Actuation Type Solenoid | ||
Seal Material Nitrile Rubber (NBR) | ||
Series 01V | ||
Solenoid Type Single | ||
Mount Type Base | ||
Number of Ports 5 | ||
Body Material Aluminium | ||
Maximum Operating Pressure 10 bar | ||
Minimum Operating Temperature -10°C | ||
Maximum Pilot Pressure 10bar | ||
Port Gender Female | ||
Minimum Pilot Pressure 1bar | ||
Maximum Flow Rate 5000NL/min | ||
Valve Function 5/3 PC | ||
Maximum Operating Temperature 60°C | ||
Solenoid Power Consumption 2W | ||
Length 275.2mm | ||
Width 30mm | ||
Hazardous Area Certification ATEX | ||
Standards/Approvals RoHS, REACH | ||
Height 60mm | ||
Electrical Connection Type Plug Socket | ||
Number of Positions 1 | ||
- COO (Country of Origin):
- IT
The RS Pro valve range is robust , versatile and combines high performances with compact installation dimensions. Solenoid, electrical, mechanical and manual operated. Large flow capacity , short change-over times and low change-over pressure. Available in 3 sizes: 1/8 - 1/4 e 1/2 .They can operate up to 10 bar working pressure. Multiple manifolds to create your own valves block. Solenoid coils are energy-saving and available in all voltage.Solenoid coils are also available.
Main advantages:
Extremely Durable
High Flow in Compact Dimension
Easy Installation
Large Range
Energy Saving
Applications:
Pneumatic Automation, Robotics, Handling
Automotive Process
Textile, Packaging, Heavy Duty
Food Process
