Pushwheel Switch BCD Pushwheel Through Hole PCB 100mΩ

  • RS Stock No. 692-6942P
  • Mfr. Part No. SH6-131-AKK2
  • Brand APEM
Technical Reference
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): DE
Product Details

APEM SH6 Sub-Miniature Pushwheel

APEM's smallest panel mounted pushwheel. Snap action with audible click.

Panel mount hole 15 x 6mm
Insertion from front and rear
Gold wiping action contacts

Specifications
Attribute Value
Output Coding BCD
Switch Readout 0 to 9
Actuator Type Pushwheel
Terminal Type Through Hole
Mounting Type PCB
Contact Resistance 100mΩ
Contact Material Gold Over Nickel Plated Copper Alloy
Minimum Operating Temperature -20°C
Maximum Operating Temperature +80°C
Operating Temperature Range -20 +80°C
Current Rating 100 mA @ 40 V
80 In stock for delivery within 1 working days
Price Each (Supplied in a Tube)
kr 102,33
(exc. VAT)
kr 127,91
(inc. VAT)
Units
Per unit
5 - 9
kr 102,33
10 - 24
kr 93,62
25 +
kr 84,91
Packaging Options:
