Circular Connectors

Circular connectors are made of multi-pin interconnects paired with cylindrical housing containing a contact interface. They can be made of plastic, metal, or a combination of both. Like most kinds of electrical connectors, their function is to enable a secure signal and current transmission by pairing a male half (the pins) to a female receptacle (the housing).

What are the benefits of circular connectors?

Circular connectors have increasingly been used in electronics due to their advantages over their rectangular counterparts. Because of their structure, one of their immediate benefits is the fact they can group several contacts in a compact space, enabling a space-saving and simple solution to disconnect and reconnect cables from their devices. However, they are also particularly convenient for:

  • Housing different kinds of contacts
  • Allowing contacts with different currents thanks to the extensive range of allowable voltages
  • Sealing hermetically where an absolute integer connection is needed
  • Conveying a strong mechanical performance in environmentally demanding applications

What are circular connectors used for?

Depending on their design and layout (threaded, push-pull, as well as many otherS), their use might be more suitable to certain applications rather than others, but in general the advantages brought by a circular connector make their range of applications very broad, from data and communication to military and aerospace industries. The high performance required by harsh industrial environments makes it necessary for the circular connector to be rugged and shielded against EMI to avoid any damage from water contamination, dirt, extreme temperature or vibration.

How do circular connectors work?

Different components are available to maximise the function of your circular connector, and our range includes:

Available from recognised worldwide brands, such as Amphenol, Deutsch, TE Connectivity and our own RS Pro.

Relaterte Produkter
These TXR series MIL-C-38999 tinel lock adapters designed ...
Description:
These TXR series MIL-C-38999 tinel lock adapters designed to terminate a braided cable shield to a connector (Raychem code 40 D38999 connector (see note). These Tinel Lock adapters are a two piece system and consist of a aluminium alloy modified ...
The NL series of industrial connectors offers a ...
Description:
The NL series of industrial connectors offers a standard configuration which is intermatable with MIL-C-38999 Series III connectors. The connectors are fitted with a first make last break earth contact and metal backshell which offers excellent shielding capabilities. Scoop-proof design ...
Bandlock Adaptor – Effective for the termination of ...
Description:
Bandlock Adaptor – Effective for the termination of screens, using tempered bands. Aluminium Alloy, Zinc Cobalt platedStraight and 90 degree (Chimney Pot) availableSuitable for overmouldingLow DC resistanceRohs compliant.
This adapter provides a connection from protective hoses ...
Description:
This adapter provides a connection from protective hoses with metal core e.g. Shureseal¹ to the Toughcon series. This results in a flexible, safe and hard-wearing connection, and a homogenous, self-contained unit. Material Aluminium anodised, galvanised steel, nylonTemperature range -55°C to ...
