Magnatec BDX34C PNP Darlington Pair, 10 A 100 V HFE:750, 3-Pin TO-220
- RS Stock No.:
- 168-5782
- Mfr. Part No.:
- BDX34C
- Brand:
- Magnatec
Available to back order for despatch when stock is available
Added
Price Each (In a Tube of 50)
Kr. 3,916
(exc. VAT)
Kr. 4,895
(inc. VAT)
| Units | Per unit | Per Tube* |
| 50 + | Kr. 3,916 | Kr. 195,80 |
| *price indicative | ||
Alternative
This product is not currently available. Here is our alternative recommendation.
- RS Stock No.:
- 168-5782
- Mfr. Part No.:
- BDX34C
- Brand:
- Magnatec
Technical Reference
Legislation and Compliance
Product Details
Bipolar Transistors, Magnatec
A range of specialized bipolar transistors from Magnatec/Semelab which includes complementary Darlington Power Transistors and High-power, High-current TO3 devices.
Bipolar Transistors, Magnatec
Specifications
Attribute | Value |
|---|---|
| Transistor Type | PNP |
| Maximum Continuous Collector Current | 10 A |
| Maximum Collector Emitter Voltage | 100 V |
| Package Type | TO-220 |
| Mounting Type | Through Hole |
| Pin Count | 3 |
| Transistor Configuration | Single |
| Number of Elements per Chip | 1 |
| Minimum DC Current Gain | 750 |
| Maximum Collector Base Voltage | 100 V |
| Maximum Collector Emitter Saturation Voltage | 2.5 V |
| Maximum Collector Cut-off Current | 0.2mA |
| Maximum Operating Temperature | +150 °C |
| Minimum Operating Temperature | -65 °C |
| Width | 4.6mm |
| Length | 10.4mm |
| Height | 9.15mm |
| Dimensions | 10.4 x 4.6 x 9.15mm |
