SMC Pneumatic Solenoid Valve - 3/2 NC Solenoid/Spring Rc SYJ5000 Series 24V dc
- RS Stock No.:
- 907-6582
- Mfr. Part No.:
- SYJ514-5LOU-Q
- Brand:
- SMC
Subtotal (1 unit)*
Kr. 639,38
(exc. VAT)
Kr. 799,22
(inc. VAT)
FREE delivery for online orders over 750,00 kr
In Stock
- Plus 9 unit(s) shipping from 10 August 2026
- Plus 10 unit(s) shipping from 10 August 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | Kr. 639,38 |
*price indicative
- RS Stock No.:
- 907-6582
- Mfr. Part No.:
- SYJ514-5LOU-Q
- Brand:
- SMC
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SMC | |
| Product Type | Pneumatic Solenoid Valve | |
| Port Type | Threaded | |
| Connection Thread Standard | Rc | |
| Actuation Type | Solenoid/Spring | |
| Seal Material | Rubber | |
| Voltage | 24V dc | |
| Series | SYJ5000 | |
| Solenoid Type | Single | |
| Mount Type | Base | |
| Number of Ports | 3 | |
| Maximum Operating Pressure | 0.7 Mpa | |
| Body Material | Aluminium | |
| Maximum Flow Rate | 245.38NL/min | |
| Valve Function | 3/2 NC | |
| Minimum Operating Temperature | -10°C | |
| Maximum Pilot Pressure | 0.7MPa | |
| Minimum Pilot Pressure | 0.15MPa | |
| Port Gender | Female | |
| Maximum Operating Temperature | 50°C | |
| Solenoid Power Consumption | 0.55W | |
| Hazardous Area Certification | No | |
| Height | 28.1mm | |
| Width | 16mm | |
| Length | 63.1mm | |
| Standards/Approvals | RoHS | |
| Electrical Connection Type | L-Plug Connector | |
| Number of Positions | 2 | |
| Select all | ||
|---|---|---|
Brand SMC | ||
Product Type Pneumatic Solenoid Valve | ||
Port Type Threaded | ||
Connection Thread Standard Rc | ||
Actuation Type Solenoid/Spring | ||
Seal Material Rubber | ||
Voltage 24V dc | ||
Series SYJ5000 | ||
Solenoid Type Single | ||
Mount Type Base | ||
Number of Ports 3 | ||
Maximum Operating Pressure 0.7 Mpa | ||
Body Material Aluminium | ||
Maximum Flow Rate 245.38NL/min | ||
Valve Function 3/2 NC | ||
Minimum Operating Temperature -10°C | ||
Maximum Pilot Pressure 0.7MPa | ||
Minimum Pilot Pressure 0.15MPa | ||
Port Gender Female | ||
Maximum Operating Temperature 50°C | ||
Solenoid Power Consumption 0.55W | ||
Hazardous Area Certification No | ||
Height 28.1mm | ||
Width 16mm | ||
Length 63.1mm | ||
Standards/Approvals RoHS | ||
Electrical Connection Type L-Plug Connector | ||
Number of Positions 2 | ||
- COO (Country of Origin):
- JP
M5 SYJ500/5000 Valves
The SYJ series of valves have low power consumption and therefore decreased engineering costs. Their space saving design means that the SYJ valves can be individually mounted onto sub plates or configured onto base mounted manifolds. These SYJ500 & 5000 valves have a pilot exhaust and have a copper free design.
Copper free design
Low power consumption
Space efficient
SMC SYJ & VF Series
Low power consumption enables direct operation by PLC. They have a non locking manual override. Operating temperature: -10 to +50°C.
