Lapp NYY-J 4 mm² 5 Core Power Cable, Black PVC, 50m

RS Stock No.:: 721-0728
Distrelec Article No.:: 304-01-846
Mfr. Part No.:: 15500263
Brand:: Lapp

Lapp NYY-J 4 mm² 5 Core Power Cable, Black PVC, 50m

Subtotal (1 reel of 50 metres)*

Kr.4 732 60

(exc. VAT)

Kr.5 915 75

(inc. VAT)

FREE delivery for online orders over 500,00 kr

Temporarily out of stock

4 unit(s) shipping from 16. januar 2026
Plus 8 unit(s) shipping from 30. januar 2026

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Reel(s)	Per Reel	Per Metre*
1 +	Kr. 4 732,60	Kr. 94,652

*price indicative

RS Stock No.:: 721-0728
Distrelec Article No.:: 304-01-846
Mfr. Part No.:: 15500263
Brand:: Lapp

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Lapp
	Cross Sectional Area	4 mm²
	Number of Cores	5
	Sheath Colour	Black
	Length	50m
	Current Rating	34 A
	CPR Certification	Eca
	Outer Diameter	23mm
	Sheath Material	PVC
	Voltage Rating	1 kV, 600 V
	Conductor Strand Type	Solid
	Insulation Material	PVC
	Fire Behaviour	Flame Retardant
	Series	NYY-J
	Standards Met	Euroclass Eca
	Core Strands	2.25 mm
	American Wire Gauge	11 AWG
	Conductor Resistance	4.61 Ω/km
	Conductor Material	Bare Copper
	Size of Strands	2.25 mm
	Maximum Operating Temperature	+50°C
	Minimum Operating Temperature	+5°C

	Select all
	Brand Lapp
	Cross Sectional Area 4 mm²
	Number of Cores 5
	Sheath Colour Black
	Length 50m
	Current Rating 34 A
	CPR Certification Eca
	Outer Diameter 23mm
	Sheath Material PVC
	Voltage Rating 1 kV, 600 V
	Conductor Strand Type Solid
	Insulation Material PVC
	Fire Behaviour Flame Retardant
	Series NYY-J
	Standards Met Euroclass Eca
	Core Strands 2.25 mm
	American Wire Gauge 11 AWG
	Conductor Resistance 4.61 Ω/km
	Conductor Material Bare Copper
	Size of Strands 2.25 mm
	Maximum Operating Temperature +50°C
	Minimum Operating Temperature +5°C

LAPP Power Cable, 5 Cores, 50m Length - 15500263

Use this versatile cable from LAPP to route power supplies and control networks above and below ground. It's constructed with 5 cores of bare copper to maximise conductivity and is stranded for flexibility and easy handling. The cores are protected by PVC insulation and a filling compound. This is wrapped in an outer PVC sheath to create a rugged cable that's suitable for burying and routing through concrete and brickwork.

Features & Benefits

• Resistant to moisture and UV rays for use outdoors
• Standard colour-coded cores to simplify connections
• Flame retardant material to help keep installations fire-safe

Applications

• Building installations
• Industrial automation
• Power distribution
• Lighting circuits

Can I use this power cable in cold environments?

Yes. Once installed, this power cable has a wide operating temperature range of -40°C to + 70°C, making it useful in processing, warehouse and cold-chain environments.

Power Cable
